Recommended for wide range of chemicals such as minerals acids, alkalies & Other Chemicals
Smooth in bore made from Natural and Synthetic Rubber
High Tensile Synthetic Yarn.
-40oF to +250oF.
1. Rubber Cover Resistant Chemicals
2. Wrap Finish
Inner Tube - Black & Outer Cover - Black Wrap Finish,
Our Product meet all requirement of Indian and Global Standards,
Part No. | ID | OD | Maximum Working Presure | Minimum Burst Pressure | WT. | Standard Length | |||
---|---|---|---|---|---|---|---|---|---|
MM ± .5mm | INCH | MM ± .5mm | PSI | BAR | PSI | BAR | KGS. | MTR | |
GCH-1219 | 12.5 | 1/2 | 19 | 170 | 12 | 700 | 48 | 0.300 | 50 or 100 |
GCH-1930 | 19.0 | 3/4 | 30 | 170 | 12 | 700 | 48 | 0.650 | 50 or 100 |
GCH-2536 | 25.0 | 1 | 36 | 170 | 12 | 700 | 48 | 0.900 | 50 |
GCH-3245 | 32.0 | 1.1/4 | 45 | 170 | 12 | 700 | 48 | 1.200 | 40 |
GCH-3854 | 38 | 1.1/2 | 54 | 170 | 12 | 700 | 48 | 1.800 | 40 |
GCH-5168 | 51 | 2 | 68 | 170 | 12 | 700 | 48 | 2.900 | 40 |
