Ganga Sand Shot Blasting Rubber Hose


Application :

Suitable for conveying all commonly used material for blasting , such as steel shot, steel grit, garnet, copper stag,Coal stag, Aluminium Oxide, Glass Breeds etc

Construction Tube :

Synthetic & Natural Rubber Blend resistant to abrasion

Reinforcement :

Two Braid High Tensile Synthetic Yarn with anti-Static Copper helix Wire.

Temp Range :

-40oc to +80oc.

Cover :

Black, NR / Cover-Resistant to abrasion and Weather.

Properties :

Flexible, high abrasion resistance.

Colour :

Inner Tube - Black & Outer Cover - Black Wrap Finish,

Application Std :

IS:5894,ISO-3861

Standard :

Our Product meet all requirement of Indian and Global Standards,





Part No. ID OD Maximum Working Presure Minimum Burst Pressure WT. Standard Length
MM ± .5mm INCH MM ± .5mm PSI BAR PSI BAR KGS. MTR
GSBH-1227 12.5 1/2 27 145 10 580 40 0.550 40
GSBH-1936 19.0 3/4 36 145 10 580 40 1.040 40
GSBH-2543 25.0 1 43 145 10 580 40 1.440 40
GSBH-3250 32.0 1.1/4 50 145 10 580 40 1.880 40
GSBH-3858 38 1.1/2 58 145 10 580 40 2.010 40
GSBH-5070 50 2 70 145 10 580 40 2.700 40
