Suitable for conveying all commonly used material for blasting , such as steel shot, steel grit, garnet, copper stag,Coal stag, Aluminium Oxide, Glass Breeds etc
Synthetic & Natural Rubber Blend resistant to abrasion
Two Braid High Tensile Synthetic Yarn with anti-Static Copper helix Wire.
-40oc to +80oc.
Black, NR / Cover-Resistant to abrasion and Weather.
Flexible, high abrasion resistance.
Inner Tube - Black & Outer Cover - Black Wrap Finish,
IS:5894,ISO-3861
Our Product meet all requirement of Indian and Global Standards,
Part No. | ID | OD | Maximum Working Presure | Minimum Burst Pressure | WT. | Standard Length | |||
---|---|---|---|---|---|---|---|---|---|
MM ± .5mm | INCH | MM ± .5mm | PSI | BAR | PSI | BAR | KGS. | MTR | |
GSBH-1227 | 12.5 | 1/2 | 27 | 145 | 10 | 580 | 40 | 0.550 | 40 |
GSBH-1936 | 19.0 | 3/4 | 36 | 145 | 10 | 580 | 40 | 1.040 | 40 |
GSBH-2543 | 25.0 | 1 | 43 | 145 | 10 | 580 | 40 | 1.440 | 40 |
GSBH-3250 | 32.0 | 1.1/4 | 50 | 145 | 10 | 580 | 40 | 1.880 | 40 |
GSBH-3858 | 38 | 1.1/2 | 58 | 145 | 10 | 580 | 40 | 2.010 | 40 |
GSBH-5070 | 50 | 2 | 70 | 145 | 10 | 580 | 40 | 2.700 | 40 |
