Recommended for in Steel Mills, Thermal Plants, Oil MIlls, Fertilizer Plants, Petroleum Refinery, For conveying saturated steam at a specified steam pressure
Smooth Uniform in bore made from EPDM Rubber Compound.
High Tensile Synthetic yarn.
EPDM Rubber compound resistant to abrasion and Abrasion.
Up to +170oc
Our Product meet Indian and Global Standards.
Inner & Outer Black or As per Customer Requirement
Part No. | ID | OD | Maximum Working Presure | Minimum Burst Pressure | WT. | Standard Length | |||
---|---|---|---|---|---|---|---|---|---|
INCH | MM ± .5mm | MM ± .5mm | PSI | BAR | PSI | BAR | KGS. | MTR | |
GSY-1220 | 1/2 | 12.50 | 20 | 145 | 10 | 580 | 40 | 0.450 | 50-100 |
GSY-1627 | 5/8 | 16.00 | 27 | 145 | 10 | 580 | 40 | 0.600 | 50-100 |
GSY-2030 | 3/4 | 20.00 | 30 | 145 | 10 | 580 | 40 | 0.650 | 50-100 |
GSY-2538 | 1 | 25.00 | 38 | 145 | 10 | 580 | 40 | 1.000 | 50-100 |
GSY-3145 | 1.1/4 | 31.50 | 45 | 145 | 10 | 580 | 40 | 1.300 | 60 |
GSY-3854 | 1.1/2 | 38.00 | 54 | 145 | 10 | 580 | 40 | 2.000 | 60 |
GSY-5070 | 2 | 50.00 | 70 | 145 | 10 | 580 | 40 | 3.000 | 60 |
